Description

The Lascar Electronics EMA 1710 is a low cost, compact indicator which is ideally suited for low or high volume applications. The meter features a 9 segment analog style LCD to display 1V d.c. full scale reading. Other voltages and currents can be measured via the addition of 2 scaling resistors. The meter can be used in applications where the order of magnitude of the reading is more important than the value of the reading itself. It allows the operator to scan the display and receive a quick visual feedback. Installation is particularly easy; the module requires only a single round hole in the panel. A rubber seal is included, providing splashproof protection for the unit when fitted to the meter during installation.

Features:

• 9 Segment Analog Style LCD
• Color Scale
• Auto-zero
• 1V d.c. Full Scale Reading
• Single Hole Mounting
• No Calibration Required
• Splashproof
