Description

The Monarch Instruments F2A3X Frequency to Analog module converts a frequency input signal into a proportional analog voltage (0-5 DCV) or current (4-20 DCmA) output. The output signal is electrically isolated from input signal and input power source effectively eliminating troublesome ground loops. The input signal can be supplied from a Monarch sensor (measuring RPM for example) or any source of digital signal not exceeding 12 volts. The F2A3X is completely user programmable using the free downloadable PM Remote Software. A NIST certificate of calibration is also included.

Features:

• Standard DIN rail mounting
• Ethernet communications available
• 5 to 999,990 RPM range (0.083 to 150kHz)
• Compatible with most speed sensors (TTL)
• 12 to 24 DCV input power
• Alarm set point with optional relay output
• Pulse repeater output
• User configurable
• View real-time data on PC
• 4-20 DCmA or 0-5 DCV scalable output
• 10 DCV or 5 DCV sensor excitation
• Includes NIST calibration certificate
